MBTX20U Motobatt 12V AGM Battery

SKU: MBTX20U
1Review
$138.98
RRP: $154.43

+500 in Stock

Overview

Battery Motobatt AGM Rep: MBTX20U YTX20BS/LBS/CB16LB/CB/CLB Motobatt Quadflex offers the best balance between AH (ampere hours) and CCA (Cold Cranking Amps -18C). Achieving this by increasing the size of the internal plates, by utilizing the unused space found in other batteries. This is made possible through our world wide patented innovated cell connection system. Additionally, we enhance the thickness of the grid, the density of the paste, and the weight (content) of the active material to maximize the capacity allowed by its size. Revolutionary to the Battery Market. Unique BenefitsPower Experience up to 30% more capacity and power with the same size as competitor batteries, thanks to its exclusive design Safe No need to add acid and risk any accidental spillages Durable Thanks to its technology and high quality AGM it is extremely resistant to vibrations or weld breakages Maintenance Free Fully sealed and factory activated, it requires no maintenance other than keeping it charged in storage Ready to go With a voltage of over 12.5V the battery is ready to use right away New improved solid mounted terminals with threaded insertsAll Motobatt Quadflex batteries have a 12 Month Full Replacement Warranty*

Replaces

Yuasa YTX20, YTX20L, YTX20BS, YTX20HBS, YTX20LBS, YTX20HLBS, YTX20HLBSPW, YTX20H, YTX20HL, YTX20HL-PW, YB16A, YB16A2, YB16B, YB16B2, YB16HLACX, SYB16LB, YB16LA, YB16LA2, YB16LB, YB16LB2, YB16CB, YB16CLB, YB16BCX, GT16L-BS, GT16BS, CTX19-BS CTX19L-BS , GYZ20H, GYZ20L, GYZ20HL
DEKA ETX16, ETX16L, ETX20,ETX20L
ODYSSEY PC535, PC625, AGM20L, AGM16L
WPS 491-1001

Specifications

Battery TypeMBTX20U
Voltage12
CCA335
MCA395A
PHCA605A
Capacity (10HR)C10-22.5Ah, C20-23.5Ah
Weight6.50kg / 14.33Ibs
Dimensions (in / mm)6.89(175) W: 3.43(87) H: 6.10(155)
TW: 3.94(100) TH: 6.89(175)
Assembly Figure Terminal Locations4
Terminals2x Blocknut M6 (PART MPN2)
Screws2x Screws M6x12 (PART MPS4)
Terminal Caps2 Black, 2 Red PART (MPC3)
Spacers2, 20mm Bottom (Part# MPBS7),
13mm Back (Part# MPSS)

WARNING: This product can expose you to chemicals including Sodium salt, Lead and Lead, Nickel (Metallic), which are known to the State of California to cause cancer or birth defects or other reproductive harm.
For more information, visit https://www.p65warnings.ca.gov/.

Downloads

Ask a Question

Product Enquiry

Welcome to the contact us form. Please select the reason for your contact today from the drop-down menu, and let us know how to get hold of you by filling in the form and what times we can reach you. Enquires can take 24-48 hours depending on demand, but we will do our best to get right back to you!

Ratings & Reviews

1 review

  • 4 stars
  • 0 reviews
  • 3 stars
  • 0 reviews
  • 2 stars
  • 0 reviews
  • 1 star
  • 0 reviews

They're yellow because they're awesome!

by -

These batteries are great! I've gotten a little over 5 years each on my first two batteries with ZERO maintenance. I don't trickle charge, I don't pull it off the bike in the winter- I ride year-round in New York. My last one even survived a fire at the repair shop complete with smoke damage and a slightly melted outer shell- but kept on going for another year. The four terminal design works wonders with the farkles on the bike, and keeps the wiring neatly separated between the factory harness, and my add-ons.

Works great with my 2000 Kawasaki Concours.
